Noiseproof Telephone Acoustic Hood Wall Mounting Fiberglass Reinforced Polyester Material
PRODUCT SPECIFICATIONS
• Dimensions - 780*680*500 (mm)
• Weight - Approx 22 Kg
• Stock Colour - Yellow , Other color can be customized.
• Cold-rolled Stainless Steel Shelf, powder coated white
• Acoustic Insulation - 50mm Tissue faced non hygroscopic Rockwool (RW3) density 60kg/m3
• Insulation Liner - White Perforated Polypropylene 3mm thickness
• Apparatus plate - Cold-rolled Stainless Steel, 2mm thickness, powder coated white
• Mounting Brackets -Cold-rolled Stainless Steel, 6mm thickness
• YT-XYT-01 is designed for noisy internal or external installations, providing a weatherproof and quieter telephone area.
• Two vandal-proof windows allow a natural light source. And the telephone booth with fancy looking and inside lamp will provide a quiet and safety communication environment day and night.
• Manufactured in robust galvanised metal. Internally the three sides of the booth are pre-lined with 50mm non-combustible, non-hygroscopic
• acoustic insulation. This is held in place by galvanised perforated panels. An acoustic slab is place inside the roof cavity for further insulation. And telephone will be fitted to the inner back panel of the booth.
Main Features
1. Durable, lightweight, chemical-resistant body
2. Excellent low temperature impact performance
3. High-performance polyurethane sound insulation lining, anti-mildew and anti-corrosion
4. Completely maintenance-free, corrosion-resistant, free from chemical attack
5. Can be used indoors, outdoors and at sea
6. Standard color is yellow, optional color is available upon request
7. Special shape suitable for high noise areas
8. High sound insulation characteristics -24dB
9. UV resistant, suitable for harsh environments
10. Easy to fix system
Technical Parameters
| Item | Telephone Acoustic Hood |
| Type | Industrial telephone |
| Material | Fiberglass Reinforced Polyester (GRP) |
| Colors | Yellow, Can be Customized |
| Installation | Wall/ Pillar Mounting |
| Acoustic insulation | Noise Attenuation up to 24 dB |
| Window | vandal-proof tempered glass |
| Usage | Heavy Industries, Refi neries, Airport, Oil&Gas plants |
Applicatiion
Heavy Industries, Refi neries, Airport, Oil&Gas plants, Factories, Chemical plants, Bulk loading stations, Mines, Drilling rigs, Steel mills, Off shore platforms, Any high noise industrial location and more.
Package
| Unit Size: | 780 *680 *500(mm) |
| Carton Dimension: | 800 *700 *520(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 22KG |
| Gross weight: | 25KG |
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2. what can you buy from us?
Emergency Telephone,Explosion Proof Telephone,Industrial Telephone,Public Telephone,Weatherproof Telephone
3. why should you buy from us not from other suppliers?
Dedication and profession have been our pursuing goal during any procedures of our production, not only in developing and quality controlling, but also in marketing and after sales. We serve any single potential customer with special individual solutions
|
