| Brand Name: | Yuantong |
| Model Number: | YT-XYT/01 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000 pcs per month |
Fiberglass Reinforced Polyester Telephone Acoustic Hood Anti Vandal For Noisy Areas
• Dimensions - 780*680*500 (mm)
• Weight - Approx 22 Kg
• Stock Colour - Yellow , Other color can be customized.
• Cold-rolled Stainless Steel Shelf, powder coated white
• Acoustic Insulation - 50mm Tissue faced non hygroscopic Rockwool (RW3) density 60kg/m3
• Insulation Liner - White Perforated Polypropylene 3mm thickness
• Apparatus plate - Cold-rolled Stainless Steel, 2mm thickness, powder coated white
• Mounting Brackets -Cold-rolled Stainless Steel, 6mm thickness
Main Features
1. Durable, lightweight, chemical-resistant body
2. Excellent low temperature impact performance
3. High-performance polyurethane sound insulation lining, anti-mildew and anti-corrosion
4. Completely maintenance-free, corrosion-resistant, free from chemical attack
5. Can be used indoors, outdoors and at sea
6. Standard color is yellow, optional color is available upon request
7. Special shape suitable for high noise areas
8. High sound insulation characteristics -24dB
9. UV resistant, suitable for harsh environments
10. Easy to fix system
Technical Parameters
| Item | Telephone Acoustic Hood |
| Type | Industrial telephone |
| Material | Fiberglass Reinforced Polyester (GRP) |
| Colors | Yellow, Can be Customized |
| Installation | Wall/ Pillar Mounting |
| Acoustic insulation | Noise Attenuation up to 24 dB |
| Window | vandal-proof tempered glass |
| Usage | Heavy Industries, Refi neries, Airport, Oil&Gas plants |
Applicatiion
Typical applications include the offshore and onshore petrochemical industries, the power and construction industries, for commercial locations where appearances are important or industrial premises to brighten up the working environment.
Package
| Unit Size: | 780 *680 *500(mm) |
| Carton Dimension: | 800 *700 *520(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 22KG |
| Gross weight: | 25KG |
Our Service
1. OEM&ODM service is available.
2. We will do our best to meet customer's requirements.
3. We also offer extended warranties and repair services on all our deliveries.
4. We aim to respond to all product support requests within 24 hours.
|
| Brand Name: | Yuantong |
| Model Number: | YT-XYT/01 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Phone size: 780 *680 *500(mm) Packing material: corrugated box, pearl cotton lining Gross weight: 25KG Net weight: about 22KG |
| Payment Terms: | L/C, T/T, Western Union |
Fiberglass Reinforced Polyester Telephone Acoustic Hood Anti Vandal For Noisy Areas
• Dimensions - 780*680*500 (mm)
• Weight - Approx 22 Kg
• Stock Colour - Yellow , Other color can be customized.
• Cold-rolled Stainless Steel Shelf, powder coated white
• Acoustic Insulation - 50mm Tissue faced non hygroscopic Rockwool (RW3) density 60kg/m3
• Insulation Liner - White Perforated Polypropylene 3mm thickness
• Apparatus plate - Cold-rolled Stainless Steel, 2mm thickness, powder coated white
• Mounting Brackets -Cold-rolled Stainless Steel, 6mm thickness
Main Features
1. Durable, lightweight, chemical-resistant body
2. Excellent low temperature impact performance
3. High-performance polyurethane sound insulation lining, anti-mildew and anti-corrosion
4. Completely maintenance-free, corrosion-resistant, free from chemical attack
5. Can be used indoors, outdoors and at sea
6. Standard color is yellow, optional color is available upon request
7. Special shape suitable for high noise areas
8. High sound insulation characteristics -24dB
9. UV resistant, suitable for harsh environments
10. Easy to fix system
Technical Parameters
| Item | Telephone Acoustic Hood |
| Type | Industrial telephone |
| Material | Fiberglass Reinforced Polyester (GRP) |
| Colors | Yellow, Can be Customized |
| Installation | Wall/ Pillar Mounting |
| Acoustic insulation | Noise Attenuation up to 24 dB |
| Window | vandal-proof tempered glass |
| Usage | Heavy Industries, Refi neries, Airport, Oil&Gas plants |
Applicatiion
Typical applications include the offshore and onshore petrochemical industries, the power and construction industries, for commercial locations where appearances are important or industrial premises to brighten up the working environment.
Package
| Unit Size: | 780 *680 *500(mm) |
| Carton Dimension: | 800 *700 *520(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 22KG |
| Gross weight: | 25KG |
Our Service
1. OEM&ODM service is available.
2. We will do our best to meet customer's requirements.
3. We also offer extended warranties and repair services on all our deliveries.
4. We aim to respond to all product support requests within 24 hours.
