| Brand Name: | Yuantong |
| Model Number: | YT-VD105 |
| MOQ: | 1Set |
| Price: | Negotiatable |
| Payment Terms: | Western Union, L/C, T/T |
| Supply Ability: | 5000 sets per months |
Anti Vandal Industrial VOIP Phone Weatherproof IP68 Hotline Telephone
Product Description
This Industrial VoIP Phone is fully contained within a corrosion resistant cast aluminium weatherproof case, providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Our industrial VoIP phone features a corrosion-resistant, vandal-resistant cast aluminum waterproof housing with a magnetically gravitational door that completely prevents the ingress of dust and moisture, extending product life and improving product reliability and stability. It is especially suitable for installation in areas with high dust, humidity, loud noise, and outdoors.
This series of phones is specially designed for use in various extreme environments, and all electronic components are industrial-grade products that are resistant to high and low temperatures. Therefore, our phone can still be used normally in the extreme temperature environment of 70 degrees to minus 40 degrees.
Technical Parameters
| Signal voltage | 100-230VAC |
| Standby working current | ≤0.2A |
| Frequency Response | 250~3000 Hz |
| Ringing level | ≤80dB(A) |
| Amplified output power | 10～25W |
| Anticorrosion grade | WF1 |
| Ambient temperature | -20～+60℃ |
| Atmospheric pressure | 80～110KPa |
| Relative humidity | ≤95% |
| Lead hole | 3-PG11 |
| Installation method | wall-mounted |
Application
Widely used in tunnels, mining, marine, underground, subway stations, railway platforms, highways, hotels, parking lots, steel plants, chemical plants, power plants and related heavy industrial applications.
Package
| Unit Size: | 373 *282 *137(mm) |
| Carton Dimension: | 400 *352 *150(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 7.2KG |
| Gross weight: | 8.5KG |
Company Information
Yuantong was established in 2013. It has carried out overseas business in advance, and its products are exported to 120
countries and regions. In 2017, it launched domestic business. Main business: industrial telephones. Products include fiber optic
phones, IP phones, video phones, and SIP Telephones, industrial analog telephones, WIFI telephones, satellite telephones,
explosion-proof telephones, dispatch management systems, etc. The products are mainly used in highways, urban underground
comprehensive pipe corridors, railways, mining, petroleum, metallurgy, chemical, electric power and other fields.
|
|
| Brand Name: | Yuantong |
| Model Number: | YT-VD105 |
| MOQ: | 1Set |
| Price: | Negotiatable |
| Packaging Details: | Phone size: 373 *282 *137(mm) Packing material: corrugated box, pearl cotton lining Gross weight: 8.5KG Net weight: about 7.2KG |
| Payment Terms: | Western Union, L/C, T/T |
Anti Vandal Industrial VOIP Phone Weatherproof IP68 Hotline Telephone
Product Description
This Industrial VoIP Phone is fully contained within a corrosion resistant cast aluminium weatherproof case, providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Our industrial VoIP phone features a corrosion-resistant, vandal-resistant cast aluminum waterproof housing with a magnetically gravitational door that completely prevents the ingress of dust and moisture, extending product life and improving product reliability and stability. It is especially suitable for installation in areas with high dust, humidity, loud noise, and outdoors.
This series of phones is specially designed for use in various extreme environments, and all electronic components are industrial-grade products that are resistant to high and low temperatures. Therefore, our phone can still be used normally in the extreme temperature environment of 70 degrees to minus 40 degrees.
Technical Parameters
| Signal voltage | 100-230VAC |
| Standby working current | ≤0.2A |
| Frequency Response | 250~3000 Hz |
| Ringing level | ≤80dB(A) |
| Amplified output power | 10～25W |
| Anticorrosion grade | WF1 |
| Ambient temperature | -20～+60℃ |
| Atmospheric pressure | 80～110KPa |
| Relative humidity | ≤95% |
| Lead hole | 3-PG11 |
| Installation method | wall-mounted |
Application
Widely used in tunnels, mining, marine, underground, subway stations, railway platforms, highways, hotels, parking lots, steel plants, chemical plants, power plants and related heavy industrial applications.
Package
| Unit Size: | 373 *282 *137(mm) |
| Carton Dimension: | 400 *352 *150(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 7.2KG |
| Gross weight: | 8.5KG |
Company Information
Yuantong was established in 2013. It has carried out overseas business in advance, and its products are exported to 120
countries and regions. In 2017, it launched domestic business. Main business: industrial telephones. Products include fiber optic
phones, IP phones, video phones, and SIP Telephones, industrial analog telephones, WIFI telephones, satellite telephones,
explosion-proof telephones, dispatch management systems, etc. The products are mainly used in highways, urban underground
comprehensive pipe corridors, railways, mining, petroleum, metallurgy, chemical, electric power and other fields.
