| Brand Name: | Yuantong |
| Model Number: | YT-IPSG20 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000 sets per month |
Weatherproof Handset Telephone Wall Hotline Analog Telephone Emergency Tunnel Metro Railway
This Analog Version Industrial Telephone is fully contained within a corrosion resistant cast aluminium weatherproof case, which providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Analog Version Industrial Telephone Powered by telephone lines, cold-rolled steel sprayed shell/nylon fiber-reinforced shell, strong and durable, good airtightness, anti-violent damage receiver, withstand repeated knocks by adults without breaking, protection grade IP68, industrial-grade silicone buttons, wall-mounted installation, The phone has good stability and strong anti-interference ability. The built-in power amplifier can be connected to a 30W radio speaker.
As a standard analog telephone, the unit provides basic telephone functions and can be connected to any standard two-wire telephone line, including analog PABX lines and PSTN.Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Technical Parameters
| Temperature | -40℃~75℃ |
| Relative humidity | 10%~95% |
| Power Supply | Analog Telephone Network |
| Supply Voltage | 24 VDC to 65 VDC |
| Supply Current | 20 mA DC to 100 mA DC |
| Atmospheric pressure | 86~106Kpa |
| Environmental noise | ≤60dB(A) |
| Ringing tone level | ≥80dB |
| Low frequency | 697-941Hz |
| High frequency group | 1209-1477Hz |
| Frequency offset | Not more than±1.5% |
| Call transmission indicators | SLR≤12,RLR≤-1,STMR≥10 |
| Output Impedance | 600Ω |
| Dial mode | full keyboard dial / off-hook automatic dial |
| Communication distance | 5 kilometers |
| Power supply | telephone line |
Features
1. Standard SIP/VOIP telephone, available for Analogue, GSM/3G phone
2. Robust housing, constructed of stainless steel
3. Vandal resistant metal button and rugged keypad(backlight keypad optional)
4. Hands free operation
5. Can be programmed remotely by tone phone
6. Non-volatile memory
7. Flush mounting, simple installation
8. Weather protection IP68
9. 4 X Tamper proof screws for mounting
10. Fast-fit terminal connection
11. Telephone line powered (Analogue)
12. CE, FCC, RoHS, ISO9001 compliant
13. Built-in amplifier, with external ringer and lamp:15W (30W optional), broadcasting feature
Application
This weatherproof Analog Version Industrial Telephone With Beacon is very popular for Tunnels, Mining, Marine, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants and related heavy duty industrial application, etc.
Package
| Unit Size: | 373 *282 *137(mm) |
| Carton Dimension: | 400 *352 *150(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 6KG |
| Gross weight: | 7.5KG |
FAQ
Q1. How to place an order? What about prices?
A1: Place an inquiry or contact with online service. After receiving your inquiry, we will reply you with prices and information or catalog.
Q2. Can I have my logo printed on the products and packing?
A2: OEM are welcome.
Q3. What is your payment terms?
A3: For sample: PayPal, West Union; for mass order: T/T ,L/C, Paypal, and others
Q4. What would the delivery time of the sample be?
A4: Regularly 3-7 days
|
|
| Brand Name: | Yuantong |
| Model Number: | YT-IPSG20 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Phone size: 373 *282 *137(mm) Packing material: corrugated box, pearl cotton lining Gross weight: 7.5KG Net weight: about 6KG |
| Payment Terms: | L/C, T/T, Western Union |
Weatherproof Handset Telephone Wall Hotline Analog Telephone Emergency Tunnel Metro Railway
This Analog Version Industrial Telephone is fully contained within a corrosion resistant cast aluminium weatherproof case, which providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Analog Version Industrial Telephone Powered by telephone lines, cold-rolled steel sprayed shell/nylon fiber-reinforced shell, strong and durable, good airtightness, anti-violent damage receiver, withstand repeated knocks by adults without breaking, protection grade IP68, industrial-grade silicone buttons, wall-mounted installation, The phone has good stability and strong anti-interference ability. The built-in power amplifier can be connected to a 30W radio speaker.
As a standard analog telephone, the unit provides basic telephone functions and can be connected to any standard two-wire telephone line, including analog PABX lines and PSTN.Equipped with horn, the horn can broadcast remotely for notification, horn works after 1-9 rings (adjustable), shut when handset lifted or call finished. Horn works after 1-9 rings, shut when handset lifted or call finished.
Technical Parameters
| Temperature | -40℃~75℃ |
| Relative humidity | 10%~95% |
| Power Supply | Analog Telephone Network |
| Supply Voltage | 24 VDC to 65 VDC |
| Supply Current | 20 mA DC to 100 mA DC |
| Atmospheric pressure | 86~106Kpa |
| Environmental noise | ≤60dB(A) |
| Ringing tone level | ≥80dB |
| Low frequency | 697-941Hz |
| High frequency group | 1209-1477Hz |
| Frequency offset | Not more than±1.5% |
| Call transmission indicators | SLR≤12,RLR≤-1,STMR≥10 |
| Output Impedance | 600Ω |
| Dial mode | full keyboard dial / off-hook automatic dial |
| Communication distance | 5 kilometers |
| Power supply | telephone line |
Features
1. Standard SIP/VOIP telephone, available for Analogue, GSM/3G phone
2. Robust housing, constructed of stainless steel
3. Vandal resistant metal button and rugged keypad(backlight keypad optional)
4. Hands free operation
5. Can be programmed remotely by tone phone
6. Non-volatile memory
7. Flush mounting, simple installation
8. Weather protection IP68
9. 4 X Tamper proof screws for mounting
10. Fast-fit terminal connection
11. Telephone line powered (Analogue)
12. CE, FCC, RoHS, ISO9001 compliant
13. Built-in amplifier, with external ringer and lamp:15W (30W optional), broadcasting feature
Application
This weatherproof Analog Version Industrial Telephone With Beacon is very popular for Tunnels, Mining, Marine, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants and related heavy duty industrial application, etc.
Package
| Unit Size: | 373 *282 *137(mm) |
| Carton Dimension: | 400 *352 *150(mm) |
| Packaging materials: | corrugated box, pearl cotton lining |
| Net Weight: | 6KG |
| Gross weight: | 7.5KG |
FAQ
Q1. How to place an order? What about prices?
A1: Place an inquiry or contact with online service. After receiving your inquiry, we will reply you with prices and information or catalog.
Q2. Can I have my logo printed on the products and packing?
A2: OEM are welcome.
Q3. What is your payment terms?
A3: For sample: PayPal, West Union; for mass order: T/T ,L/C, Paypal, and others
Q4. What would the delivery time of the sample be?
A4: Regularly 3-7 days
